Winner of the Good Design Award!
A New Era of Lightweight Transport: Fusing Air and Magnetic Forces

Good Design Award 2024 logo
Altasia∞ next-generation lightweight transport system with magnetic motion, flexible layout, multi-route distribution, and easy maintenance
Design Flexible Routes with Greater Layout Freedom
Enable Circulation and Sorting Using Airflow
Outperform Belts and Chains in Durability
Reduce Wear and Lower Operating Costs

Next-Generation Lightweight Transport System Featuring Magnetic Coupling

POINT1

Magnetic Coupling:

The shuttle unit on the upper rail is magnetically synchronized with the air-driven unit  that travels inside the air duct. By this magnetic coupling, lightweight items placed on the shuttle are transported smoothly and efficiently.

Diagram of a magnetic coupling system showing a shuttle unit transporting 15 kg loads, moved by an air-driven unit through an air duct via magnetic force.

●Capable of transporting items weighing up to 15 kg

 (Note: Customization may be required depending on the nature of the items.)

●One air-driven unit can transport two shuttles simultaneously, allowing a combined payload of up to 30 kg per cycle

POINT2

Circulation Function:
Switching the circulation valve enables continuous airflow cycling. Flow direction can also be reversed through valve control.

Diagram of Altasia∞ transport system showing circulation valve operation for switching airflow direction using open and closed valve states
POINT3

Flow Path Switching:
By switching the switch valve, the transport path can be redirected to either the left or right route.

Diagram showing the internal structure of a switch valve in the Altasia∞ system and how airflow is directed left or right depending on valve position
POINT4

Precise Stopping at Designated Positions:

The system enables precise stopping using magnetic attraction and eddy current braking mechanisms.

Diagram of Altasia∞ transport system showing magnetic attraction stopping mechanism and eddy current brake for deceleration on aluminum rail
拡大
Diagram of Altasia∞ transport system showing magnetic attraction stopping mechanism and eddy current brake for deceleration on aluminum rail

2024 GOOD DESIGN AWARD
