■ High-precision optical sensors and robust design
■ 4 denominations and major currencies are available

Deposit Denominations

Japanese banknote 4 denominations

(1,000 yen/ 2,000 yen/ 5,000 yen/ 10,000 yen)

Deposit Speed

1 note for 2 seconds

Cash Box Capacity

500 notes including all denominations in one box

High durability for a wide range of environments

Resistant to water, dust, and ambient light, and can operate in environments as low as -15°C.

Centering mechanism supports validation and transfer

The banknote centering mechanism ensures stable transport and reliable validation of deposited banknotes. It also supports validation of foreign banknotes.

Hybrid cash box using a combination of metal frame and plastic

3 capacity types

Three Cash box options of 500/ 1,000/ 1,400 notes, depending on the applications.

Easy maintenance

The validation and transport units can be accessed from the rear.
One touch opening/closing of validation unit and detachable cash box allow for easy maintenance.

Specifications

Name

Bill Validator DBV-500

Dimensions in mm

104 (W) × 154 (D) × 272 (H)

(for 500 notes cash box)

Weight

Approx. 2kg

Supply Voltage

DC12V、DC24V

Interface

RS-232C、USB

Option

Cash box capacity options of 1,000/ 1,400 notes
