■ 4-Denomination Bill Recycler
■ Automatic Banknote Counting and Replenishment Available as an Option

Main Applications: Retail Payment Terminals
Main Applications: Retail Payment Terminals
Image of UBAPro-RT / UBAPro-RQ four-denomination bill recycling unit

Supported Banknote Size

W: 62 - 82mm, L: 120 - 170mm

Acceptance Capacity

Single-note insertion

Acceptance Speed

Approx. 3.2 seconds per note

Storage Capacity

Recycling Units: Two drums, 30 notes each

*Up to two recycling units can be installed.

Collection Box: Approx. 400 notes

(Up to 1,000 notes with optional large-capacity box)

Dispense Capacity

Single-note dispensing

Dispense Speed

Approx. 2 seconds per note

Four-Denomination Recycling Units

The recycling units of this device utilize a drum-based mechanism, allowing each drum to store approximately 30 notes by winding them inside.
Each recycling unit is equipped with two drums, and up to two recycling units can be installed, enabling recycling of up to four denominations.

Configurable to Meet Various Applications

As a factory option, the unit can be configured in multiple combinations to suit specific operational requirements, offering flexible solutions for a wide range of needs.

Image showing UBAPro Twin SH400, UBAPro Twin SS800, and UBAPro Quad SH400 bill recycling units

Specifications

Name

4-Denomination Bill Recycling Unit UBAPro-RT™/UBAPro-RQ™

Dimensions

W114 × D229 × H547 mm (excluding projections)

Weight

Approx. 11kg

Supply Voltage

DC24V

Interface

RS232-C
